Label Die Cutting Machine

Label Die Cutting Machine
Label Die Cutting Machine
Send Inquiry
Product Code : FUHM-320 420
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
Product Description
We are engaged in delivering precise Label Die Cutting Machine in both FUHM-320 and FUHM-420 models. This machine is available in 2600x950x1400mm & 2800x1050x1400mm dimensions and 1500kg & 1800 kg weights. It is highly demanded in various industries due to its 30-145m/min & 30-130m/min die cutting capacities, automatic operation and user-friendly interface. Apart from this, our provided Label Die Cutting Machine uses a paper roll of 320mm and 420mm widths.

Key features:
  • Used to cut label die in 300mm and 400mm sizes
  • Consumes 2.5kw power and 1.1kw main motor power
  • Requires less maintenance and simple construction
  • import servo motor, import screen , import inverter
  • use flat press ,high precision die cutting , transmission material and cutting by computer control
  • printing mark and lengthways control by 3pcs photocell
  • suitabel for label , dacron film label , laser anti-fake label and electricity label die cutting

PARAMETER

 Modle

 FUHM-320

 FUHM-420

 Die cutting speed

 30-145m/min

 30-130m/min

 the max diameter of unwinding

 450mm

 450mm

 The max width of paper roll

 320mm

 420mm

 The max width of die cutting

 300mm

 400mm

 The max length of die cutting

 300

 400mm

 Positional accuracy

 ±0.15

 ±0.10mm

 Main motor power

 1.1kw

 3.7kw

 Total power

 2.5kw

 5.5kw

 Voltage

 220v±10%

 380v±10%

 weight

 1500kg

 1800kg

 dimension

 2600x950x1400mm

 2800x1050x1400mm
