Middle Speed Paper Cup Forming Machine

Middle Speed Paper Cup Forming Machine
Middle Speed Paper Cup Forming Machine
Product Code : FH-12D
Product Description

FH-12D Middle Speed Paper Cup Forming Machine

FEATURES

FH-12D Middle Speed Paper Cup (Bowl) Forming Machine is designed on the basis of a normal speed paper cup forming machine with high intensity and stability. It is designed to ensure efficient silicon oil lubrication, knurling, bottom punching heating, curling as well as cup discharge. It develops durable and safe to use cups widely used in beverages, ice cream and other sectors. This is designed with novel technologies using imported hot blowing equipment along with high speed precise cam indexing unit to ensure to provide great results.

PARAMETER

 Model

 FH-12D

 Cup Size

 6-12oz(cup mouth diameterф70mm-ф90mm/bottom outside
 diameterф40mm~ф  70mm/height65~120mm/bottom depth 5~10mm)

 Output

 60-75pcs/min

 Main Moto power

 2.2kw

 Heating Power

 8kw

 Total Power

 15kw

 Air Source

 0.4m³/min, 0.5MPa

 Raw Material

 190-350g/㎡(single or double side PE coated paper

 Weight

 3100kg

 Dimension

 2950×1400×2000mm

 Collector size

 1050×850×1950mm
